Overall L*W*H:12500*2500*1570-1600mm
Payload:<80 tons
22 Foot Flatbed Trailer Specification
22 Foot Flatbed Trailer is a good option for customers who transport containers such as 20 feet or 40 feet. All of our three axle flatbed trailer use polyurethane paint that has high adhesion and provides a more beautiful color.
Flatbed trailers for sale near me use welded beams prevent deformation when carrying heavy objects.
Flatbed trailer dimensions:12500mm*2500mm*1550mm
22 Foot Flatbed Trailer Parameters
Trailer Name | 22 Foot Flatbed Trailer For Sale |
Dimensions | 12500mm*2500mm*1550mm |
Loading | 45T |
Tire | 11.00R20, 12.00R20,12R22.5, 385/ 65R22.5 Triangle brand |
Material | Main beams Q345B, upper flange:14mm, middle:8mm, down:16mm |
Axles | 13T/16/20T BPW or FUWA brand |
King Pin | 2 inch or 3.5 inch JOST Brand |
Brake System | WABCO Valve with big chamber |
LandingGears | JOST brand two-speed, Manual operating heavy duty 28ton |
Suspension | Bogie suspension, spring suspension, Air suspension |
Floor | 3mm,4mm,6mm diamond steel plate |
ElectricalSystem | 24v, 7core socket, lights according to European standards (suitable for all market) |
Twist lock | 8 or 12 sets |
Other parts | 1 tool boxs, 1 spare tire carrier |
Functions | Transport container, loose cargo, bulk cement, bulk rice,etc |
