4 Axle Tipper Trailer Truck for sale

Description

Tipper Trailer Specification

4 Axle Tipper Trailer Truck, is specially designed for heavy good transportation, like stone and mining materials. It is strong enough to carry up 80T and heavier duty in long distance delivery, rough road situation.
Tipper Trailer body is made of high-quality steel, advanced technology and strict production technology. The structure of the 4 Axle Tipper Trailer Truckis reasonable, reliable, easy to operate and beautiful. All parts are manufactured by famous manufacturers at home and abroad, and they are purchased, inspected and used in strict accordance with the requirements of quality system documents to ensure the good performance of the vehicle.
4 Axle Tipper Trailer Truck chassis adopts special chassis produced by various chassis manufacturers, with advanced technology and reliable performance.
The advanced software optimizes the design of the 4 Axle Tipper Trailer Truck to meet the individual needs of customers.
The process tooling of flow operation ensures the excellent quality of Tipper Trailer.

Tipper Trailer Parameters

Dimension(LWH)	1050026503700 (mm) (Customized Sizes or Designed according to customers’ needs)
Thickness	Side wall:8 mm; bottom floor:10 mm
Payload (Kg)	40000 to 100000
Volume (CBM)	20 to 50 CBM
Hydraulic system	HYVA Brand
Kingpin	JOST 3.5″/2.5″ bolt-in type
Landing gear	JOST 19″
Tires	11R22.5 /12R22.5/11.00R20/12.00R20
Axle	FUWA/BPW/ZY or other Brands
Suspension	Heavy duty mechanical suspension with springs/Air suspension/Bogie suspension
Brake system	Dual line with WABCO brand Re-6 emergency relay valve, T30/30 air chamber, 45L air tanks
Electric system	One unit of 24V 7-pin ISO standard socket; with brake light, turn light, reverse light, side light, reflector, fog light; one set of 6-pin standard cable

Tipper Trailer Drawings

Products picture
