Overall Dimension:17500 * 2650 *4000mm
Loading Weight:18T-28T
Car Hauler Semi Trailer Specification
Car Hauler Semi Trailer is also named car transport semi trailer, refers to a vehicle used to transport cars,which can be customized in length according to customer demands, with the frame being welded I-beam.The upper chassis can be divided into two or three parts and adjustable in height using a hoist and hydraulic cylinder.
The front panel of the enclosed type is covered with stamped small corrugated plates, while the sides are covered with either small corrugated plates or stamped corrugated plates. The top is equipped with poles and a cover. Car Hauler Semi Trailer is equipped with a toolbox, a spare tire rack, and a drip brake system to enhance the safety of vehicle transportation.
Car Hauler Semi Trailer Parameters
Trailer Model
|
Car Hauler Semi Trailer
|
Overall Dimension(L x W x H)(mm)
|
20000×2600×4200mm
|
capacity
|
10 – 12 units vehicles
|
Axle Brand
|
13T×3pcs
|
Axle Number
|
Three
|
Axle load
|
13000kg X 3
|
Suspension system
|
Standard Mechanical suspension
|
The material of Main beam
|
The height of the beam is 500 mm, top 10mm,middle 6mm,bottom 12mm;T700 high strength steel
|
Tire Type and quantity
|
Chinese brand Tire 12R22.5
|
6 pcs.
|
|
rim
|
9.0×22.5
|
Traction Pin
|
2″,diameter 50.8 mm ,loading 16 ton
|
Tool Box
|
1 Standard
|
Landing Gear
|
standard 28 ton
|
Electrical system
|
1. Voltage: 24v
|
2. Receptacle: 7 ways (7 wire harness)
|
|
Tail lamp with turn signal, brake light & reflector, side lamp etc.
|
|
One set 6-core standard Cable.
|
|
Color
|
According to customer’s requirement
|
Packing
|
Polish with wax before shipping
|
Noted
|
1.Top platform can be adjusted up and down by hydro-cylinder and chain block, totally 4 pcs of cylinder in each trailer
|
2. The roof of trailer can be down about 20cm.We can control by hand when go through limited high place as bridge or some thing.
|
