Payload:80 tons, customized
Box thickness:Bottom plate:8mm Side plate:6mm
Chinese trailers for sale Specification
Chinese trailers for sale semi dump trailer is a specially designed semi-trailer which combines the convenience of container transport and the practicality of self-unloading function. This kind of semi-trailer is not only capable of transporting containers safely and efficiently like ordinary container semi-trailers, but also has the ability to unload containers or goods automatically.
Chinese trailers for sale semi dump trailer are usually equipped with special unloading devices, such as hydraulic lifting system, tilting mechanism or rotating device, etc. These devices can be activated when needed to make containers or cargoes unloaded automatically from semi-trailers without manual labour or use of other lifting equipment. Chinese trailers for sale semi dump trailer design greatly improves loading and unloading efficiency, reduces labour costs, and lowers the risk of cargo damage due to improper manual handling.
Chinese trailers for sale semi trailer end dump truck has a wide range of application scenarios, especially suitable for occasions where frequent loading and unloading of containers or goods is required, such as harbours, wharves, logistic parks and construction sites. In these occasions, sinotruk howo trailer Chinese trailers for sale end dump semi trailer can significantly improve the transport efficiency, shorten the loading and unloading time, and enhance the overall operational efficiency.
In addition,Chinese trailers for sale end dump semi trailer also has a certain degree of flexibility and adaptability. Sinotruk howo trailer Chinese trailers for sale end dump semi trailer can be customised and modified according to different transport needs and cargo characteristics to meet specific customer requirements. For example, thermal insulation or cold storage equipment can be added to transport temperature-sensitive cargoes, or unloading devices can be adjusted to accommodate containers or cargoes of different sizes and weights.
Chinese trailers for sale Parameters
Product Name
|
Chinese trailers for sale Dump Semi Trailer
|
||
Function
|
Transport heavy Stone and Sand
|
||
Overall dimension
|
9000x2500x3600mm
|
||
Loading weight
|
60000KGS to 80000KGS
|
||
Main beam
|
Material is Q345B, The height of the beam is 500 mm, upper plate is16mm,down plate is 18mm,middle plate is 10mm.
|
||
Side beam
|
22mm channel steel
|
||
Traction pin
|
JOST Brand, optional 2″ or 3.5″
|
||
Land gear
|
Standard 28ton
|
||
Axle
|
13ton for each axle
|
||
Axle brand
|
FUWA Brand axle
|
||
Suspension type
|
3 axle mechanical suspension
|
||
Leaf spring
|
10/10/10 90mm*13mm*10pcs
|
||
Rim
|
9.00-22.5 12pcs
|
||
Tire
|
1200R20 triangle brand
|
||
Tire quantity
|
12 units
|
||
Box Size
|
Bottom 8MM Size 6MM
|
||
Valve
|
WABCO VALVE
|
||
Brake Chamber
|
6 big chamber brake system
|
||
Tool box
|
1 unit 1m*0.5m*0.5m
|
||
Spare wheel carrier
|
2 units
|
||
Side marker lamp
|
LED type
|
||
Voltage
|
24V
|
||
Receptacle
|
7ways (7 wire harness)
|
