Dimensions:18000×2500×1500mm
Tare Weight:8-14T
Container Trailer Chassis Specification
Sinotruk trailer Container Trailer Chassis’ key features ensure that shipping containers are moved safely and effectively, keeping cargo safe and following transportation rules. Here are the main benefits:
Chinese trailers for sale Container Trailer Chassis is strong and durable: chinese semi truck Shipping container trailer chassis are built from strong materials like steel, making them durable enough to transport heavy containers.
Container Trailer Chassis can be adjusted: The Container Trailer Chassis is built to fit containers of different sizes. It can be adjusted to securely hold containers of various lengths using twist locks or corner fittings.
Chinese trailers Container Trailer Chassis provides stability and support: The shipping container trailer chassis has a strong frame with cross members and reinforcements to keep the container stable and secure during transit, preventing movement or damage.
Sinotruk trailer Container Trailer Chassis can carry heavy loads: The Container Trailer Chassis is built to comply with transportation rules for weight distribution and load capacity. They can safely carry heavy loads while maintaining stability and safety.
Sinotruk trailer Container Trailer Chassis is compatible: The Container Trailer Chassis is designed to easily connect with trucks, trains, and ships. They typically have a fifth wheel or kingpin for simple attachment and detachment.
Chinese trailers for sale has safety features: Chassis often come with safety features to comply with road regulations and improve visibility. These may include lights, reflectors, and brakes. Some chassis also have locking mechanisms to secure the container during transit.
Chinese semi truck enables intermodal transportation: 7. Shipping container trailer chassis is built to easily move containers between trucks, trains, and ships, making them a key part of the logistics chain.
Container Trailer Chassis Parameters
Manufacture |
Sinotruk company |
||||
Wheel Base (Mm) |
1310 |
||||
Leaf-Spring Pcs |
10 |
||||
Axle |
13/16/18 T |
||||
Suspension |
Heavy Duty Mechanic Suspension With Leaf Springs |
||||
Main Beam Material |
Q345B Manganese Plates, Automatic Submerged Arc Welded |
||||
Brake System |
Dual Line Braking System With Automatic Braking System/Chambers |
||||
Brake Air Chamber |
Double Model |
||||
Kingpin |
2′ Or 3.5′ Interchangeable |
||||
Landing Gear |
28T Loading Capacity With 80T Static Lifting Capacity. |
||||
Platform |
Skeletal Chassis Loading Deck |
||||
Brake System |
Dual Lines Braking System With Automatic Air Chambers |
||||
Brake Air Chamber |
Four Double And Two Single Chamber |
||||
Electrical System |
24V, 7core Socket, Lights According To European Standards. |
||||
Mainbeam Size
|
Upper Plate |
14mm |
|||
Lower Plate |
16mm |
||||
Mid Web |
8 mm |
||||
Height |
500-520mm |
||||
Tool Box |
1 Box Of Standard Tools |
||||
Spare Tire Carrier |
2 Sets |
||||
Color And Logo |
Depends On The Buyer’s Requirement. |
||||
Pin Height |
According To The Height Of The Tractor Saddle. |
||||
Painting |
Three Coats Painting; Any Color Will Be Available |
||||
Other Specifications |
The Frame Can Be Flat Plate Style And Skeleton Style.Twist Lock Settings Installed 12 Pics, 8 Pics, And 4pcs To Satisfy The Containers With Different Sizes For Convince. |
||||
Application |
For 2x20ft Or 1x40ft Containers Transport |
