Home Trailer Van Semi Trailer

Dry Van Semi Trailer

Overall L*W*H14000*2550*4000mm
Tare weight68kg
Payload60Tons
Axle3 axles  FUWA/SAF/BPW  brand optional
KingpinJOST 2"/3.5" bolt-in king pin
ColorCustomized
Dry Van Semi Trailer

Description

Dry Van Semi Trailer Specification

The Dry Van Semi Trailer Refrigerated Trailer is a high-performance and versatile refrigerated transport solution designed for the demanding requirements of cold chain logistics. Engineered to maintain precise temperature control across extended distances, this trailer is an essential asset for the safe and efficient transportation of perishable goods, pharmaceuticals, and temperature-sensitive products.



Dry Van Semi Trailer Parameters

Vehicle size
14000*2550*4000 mm
Case size
13900*2450*2700 mm
Altitude
400MM (low temperature 700K2)
Upper wing
8MM/140MM
Lower wing
10MM/140MM
Ventral plate
6#
Layer two
Bended part
Side beam
Aluminum alloy track for the upper beam of the G type 3.0# outside of the bend
upright
Front and back bending pieces
Bottom plate
Bamboo plywood -28# thick after installation with sealant
Front file
Front gear, rear gear should be alive, and front gear should be laminated
Toolbox
An aluminum alloy 1.5 meters long by 0.6 meters wide by 0.5 meters high is made at the rear of the axle
Spare tire carrier
1 galvanized
Air reservoir
2 aluminum alloy cylinders of about 50 liters
Lamps and lanterns
Pull the warning light at the rear
Protective net
Made of aluminum alloy
Traction pin
JOST 50# Live pin
outrigger
Guangdong Fuhua axle 28T external legs linkage round feet
Air sac
6 airbags, whole vehicle lift, Front axle lift
axle
1840 Three Bridge 13T disc brake
tyre
Triangle 385/ 65R22.5 (7 sets)
Steel ring
Factory parts 11.75 (7 PCS)
suspension
Air suspension
Brake chamber
Double air chamber 6
Power source
39 square
bumper
Rear bumper made of aluminum alloy
Fender tile
Plastic mud tile straight

Products picture

Dry Van Semi Trailer-1

Dry Van Semi Trailer | semi trailer dry van | semi dry van trailer for sale | Box Semi Trailer

Dry Van Semi Trailer-2

Dry Van Semi Trailer | semi trailer dry van | semi dry van trailer for sale | Box Semi Trailer

Dry Van Semi Trailer-3
