Overall L*W*H:11700*2500*1700mm
Payload:45 tons
Howo Trailer Truck Price Specification
Sinotruk howo trailer series products are suitable for the transportation of various types of mechanical equipment, large objects, highway construction equipment, large tank bodies, power station equipment, and various types of steel. Chinese Sinotruk Howo semi trailer have a wide range of uses and are efficient and fast. The china sinotruk trailer truck whole vehicle adopts advanced computer-aided design software for flexible and diverse optimization design. The chinese sinotruk howo trailer truck frame bearing surface is designed according to user requirements to meet the transportation of various special goods.
Chinese trailer manufacturers – sinotruk company Factory Direct Sales and Customizable 5-Axle 6-Axle 8-Axle 50-Ton 80-Ton Semi-Trailer 20-Foot 40-Foot Low Bed Trailer Semi-Trailer.
The chinese sinotruk howo trailer truck whole vehicle is welded with low-alloy high-strength steel, reasonable structure design, and adopts 4-axis heavy axle and suspension, which has strong bearing capacity and can load 60 tons of goods.
The chinese sinotruk howo trailer truck is very suitable for the transportation of heavy machinery and equipment: tractors, buses, special purpose vehicles, rail vehicles, mining machinery, forestry machinery, construction machinery (such as excavators, bulldozers, loaders, pavers, cranes, etc.) and other heavy loads.The howo semi truck body is strong and durable, the legs are supported, and the axle adopts the internationally renowned Fuhua brand, which is safe and reliable and has a long life.
Howo Trailer Truck Price Parameters
Howo Trailer Truck Price Specification | |
Overall dimensions (length, width and height) | 17800*2550+230+230*3050 |
Cargo platform dimensions (length, width and height) | 13000*2550+230+230*950 |
curb weight | About 20000KG |
Carrying quality | 80000kg |
suspension | 8-axis air suspension + 4-axis lifting |
tire | 235/75R17.5,32 items(customizable) |
axle | 11.5T 8 pieces(customizable) |
brake | Standard configuration |
Ladder | Hydraulic ladder |
Outrigger | 28TOutrigger |
Girder configuration | The upper wing plate is 20mm, the lower wing plate is 20mm, and the web plate is 14mm. Beam height 500mm |
King pin | 90MM |
cargo platform | Bottom plate 5mm thick patterned steel plate |
light | LED: rear combination lights, side marker lights, license plate lights, brake lights. |
circuit | 24V 6-core circuit |
Electrical connection | International standard gas connector, 24V 7-pin socket |
spray paint | Color can be customized |
