Payload:80 tons, customized
Box thickness:Bottom plate:8mm Side plate:6mm
Sinotruk Semi Trailer Specification
Sinotruk Semi Trailer semi truck dump trailer are suitable for the transport of coal, ore, building materials and other bulk and scattered goods. Sinotruk Semi Trailer semi truck dump trailer can be divided into two main categories according to their use:
One class belongs to the non-road transport with heavy and ultra-heavy chinese Sinotruk Semi Trailer semi truck dump trailer mainly undertake large-scale mining, engineering and other transport tasks, usually and excavator supporting the use of.
The other class belongs to the light and medium-sized ordinary chinese Sinotruk Semi Trailer end dump semi trailer for road transport, which mainly undertakes the transport of loose goods such as gravel, soil, coal, etc., and is usually used in conjunction with the loader.
1, The carriage adopts side and rear tipping self-unloading mode, which can effectively improve the transport efficiency of the loader in transporting loose and fragmented goods.
2,The frame and longitudinal beam of the carriage are welded with high-quality manganese plate, and there are two kinds of cargo box: skip and rectangle. Chinese Sinotruk Semi Trailer end dump semi trailer has high strength, strong lifting force, rigidity, good toughness, strong bearing capacity and no permanent deformation.
3, Excellent technology:Chinese Sinotruk Semi Trailer semi truck dump trailer the main components are processed by advanced equipment, the longitudinal beam has fully automatic submerged arc welding, and the assembly machine is used for the precise assembly of wheel axle and steel plate spring.
Sinotruk Semi Trailer Parameters
name | Sinotruk Semi Trailer – semi dump trailer for sale |
Material | Steel |
Size | 9600*2500*3990mm |
Max Payload | 60tons |
Place of Origin | Sinotruk company |
Brand Name | china sinotruk international co ltd |
product name | Sinotruk Semi Trailer semi truck dump trailer |
Dimensions | 9600*2500*3990mm |
total mass | 72T |
self weight | 12T |
load | 60T |
main Beam | Q345 |
Axle | 13T/1850 Fuwa |
Traction pin height | 1300mm |
Wheeltrack | 1850mm |
tire quantity | 16 strips |
