Overall L*W*H:13750*2550*4000mm
Tare weight:8000kg
Van Semi Trailer Specification
The Van Semi Trailer body is made of high-quality steel, advanced technology and strict production technology.
The structure of the vehicle is reasonable, reliable, easy to operate and beautiful.
All parts are manufactured by famous manufacturers at home and abroad, and they are purchased, inspected and used in strict accordance with the requirements of quality system documents to ensure the good performance of the vehicle.
Van Semi Trailer Parameters
Specification | |
Tare Weight | 7225kg |
Overall Length | 12400mm |
Overall Width | 2480mm |
Payload | 60000kg |
SPECIFICATIONS | |
I Beam & Chassis | Heavy duty and extra durability designed I beam; Opting for high tensile steel Q345B, welded by automatic Submerged-Arc processes. Top Flange 14mm,width 140mm; Middle Flange 6mm,Height 500mm, Bottom Flange 16mm,width 140mm. |
Axle | 3 axles |
FUWA, BPW, L1, or 16 ton | |
Suspension | Heavy duty mechanical suspension |
Floor | 3mm checker plate |
Leaf Spring | 10 piece Leaf spring |
King Pin | JOST brand 2″ Bolt-in King Pin |
Landing Gear | JOST brand Two-speed, manual operating, heavy duty landing gear |
Wheel Rim | 9.25-22.5 steel wheel rim, 13 pieces including one spare |
Tire | 12.00R20 all steel radial tire, 13 pieces including one spare tire. |
Twist Lock | 12 nos. of ISO twist lock for 1x20ft, 2x20ft; 1x40ft container, the retractable central locks can be laid down. |
Spare Tire | One set of spare tire including a carrier |
Braking System | WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber; 45L air tanks |
Painting | Complete Chassis sand blasting to clean rust, 1 coat of anti-corrosive prime, 2 coats of final paint |
Accessories | One standard tool box |
