China Tanker Truck

Engine Weichai
Volume of Tank20000L
Total Mass24500 Kg
Dimension10350×2496×3350 mm
Rated Power336HP
China Tanker Truck

Description

China Tanker Truck Main Specification

We have plenty of clients who are engaged in the fuel transportation business. Aiming at offering suitable trucks to our clients, we have three versions: light-duty version(suitable for those markets with loading capacity restriction), medium-duty version(suitable for mixed road condition) and heavy-duty version(suitable for very bad road condition and overloading).

Usually, we use the light version to pulling fuel tank trailers, because the volume of the tank is fixed,  so basically speaking, the total weight is fixed, there is no overloading such an issue. Of course, sometimes, clients possibly load the tanker with fuel in heavy density. that is an exception. China Tanker Truck The light version horse has a 371hp or 420hp engine and equipped with MCY13Q driven axles, which is a single reduction type, fuel economic and high running speed. This version is suitable for good road conditions and non-overloading purposes.

Normally China Tanker Truck has a 400liters capacity fuel tank, but 600 liters one is optional. As we know, long-distance transportation needs a lot of fuel, to avoid fuel theft, an auxiliary fuel tank can be customized behind the cabin to secure long-distance operation without refilling, the volume can be customized from 800-1600litres.

Name China Tanker Truck
Dimension(LxWxH) 10350×2496×3350 mm
Total Mass 24500 Kg
Rated Payload 15000 Kg
Cerb Weight 11250 Kg
Passenger 3
Approach/Departure Angle 16/12
The Parameters of Chassis
Manufacture/Model HOWO/ZZ1257N4647D1
Driving Type 8*4 left/right hand drive
Wheel Base 4600 + 1350mm
Front/Rear Track 2022/1830(mm)
Tyre 12R22.5, 10+1 spare tire
Front/Rear Suspension 1500/2900(mm)
Leaf Spring Number 4/-,4/12,10/-,10/12
The Paremeters of Engine
Engine Model WD615.69
Rated Power 336hp
Fuel Type Diesel oil
Displacement/Capacity 9726ml
Emission Standard Euro 2
Manufacturer SINOTRUK
The Parameters of Equipment
Color/Logo Customizable
Material Carbon steel (optional with stainless steel, aluminum alloy)
Function Fuel/oil/diesel Transporting and refueling, etc.
Volume of Tank 20000L
Thickness 5mm
Equipment

1. Equipped with 1 oil pump with 1 inlet valve and 1 outlet valve.

2. Tank divided into 6 compartments, each discharge valve for each compartment.

3. Each European standard man hole cover and each air emergency valve for each compartment.

4. Equipped with folding barrier on top of the tank.

5. Equipped with fire extinguisher, front ladder, grounding wire, plastic fender.







Product Images

China Tanker Truck | sinotruk howo price in china | sino trucks for sale | sinotruk price in ethiopia

China Tanker Truck | sinotruk howo price in china | sino trucks for sale | sinotruk price in ethiopia



High Reliability
High Reliability
Introduce the original German MAN TG series vehicle technology, the same product design and the same production assembly technology, completely adopt the German standard in the production conformity management, testing & validation and the product release, and synchronize the parts purchasing system with MAN company, allof which are the strong guarantee of the vehicle high reliability.
Engine
Engine
DERIVING FROM MAN AND IMPROVED IN CHINA MC11 engine has a very wide area of low oil consumption and large torque, The minimum specific fuel consumption is only 186 g/kw / h; The internal mileage of the engine oil change can reach 80000 kilometers.Its B10 life could reach 1.5 million kilometers.
