Dump Truck Mining Specification
All products made by Sinotruk are well-noted for overloading, strong, tough and reliable. Dump Truck Mining perfectly explains the above features. Howo Mini Truck is the toughest series, widely used in all kinds of mines. We name them as HOWO Dump Truck Mining and HOWO MINE WARRIOR, with a loading capacity ranging from 30-90tons.
As our Dump Truck Mining has a great built quality, great economical value, carries more loads than others, every benefit of this mining tipper truck leads to smoother operations for the owner. Smoother operations mean your profitability increases as there are less number of issues to worry about. Heavy Duty Sinotruk has been in this business for 60 years and we understand the importance of a business with smoother operations on a daily routine.
Dump Truck Mining Parameters
| Brand | HOWO (SINOTRUK) |
| Cabin | HW7D side cabin, with air conditioner |
| Mining dump truck engine |
WD615.47, CNHTC brand, EuroII, 4 stroke direct injection diesel engine, 6-cylinder in line with water cooling, turbo-charging and intercooling |
| Displacement | 9.726L |
| Max. output | 371hp@2200rpm |
| Max torque | 1500Nm@1100-1600rpm |
| Bore/Stroke(mm) | 126/130 |
| Fuel type | diesel |
| Clutch | diameter Φ430mm, hydraulically operating with air assistance (1900Nm) |
| Transmission | HW19710, 10 forward, 2 reverse, with HW70 PTO(power take off), torque:1900Nm |
| Steering | ZF8098 hydraulic steering with power assistance |
| Front axle | HF12 |
| Rear axle | AC26, ratio=10.47 (8.51 is optional). Tandem axle, STR 26T hub-reduction with differential locks between wheels and axles, enforced STR axle with 4 U bolts. |
| Tyre | |
| 14.00-25 bias tire 36PR (rim: 10.0-25) | |
| Brake system | WABCO, dual brake chamber |
| Curb weight(kg) | 17300 |
| Total mass (kg) | 70000 |
| Wheelbase(mm) | 3800+1500 |
| Front/Rear Wheel track (mm) | 2741/2520 |
| Fuel Tank | 500L D-shape Al-alloy |
| Internal body size | 6000X3100X1800MM |
| Body type | Volvo type |
| Capacity | 33.48CBM |
| Thickness of steel | Bottom 14mm side&back 8mm,Mn16 steel. |
| Lifting system | Front lift, HYVA tipping system |
| Dimension (mm) | 8800*3300*3670 |
