Howo Gearbox Truck

Description

Howo Gearbox Truck Main Specification

-. Hook lift Case volume:10CBM/14CBM/ 16CBM/20CBM
-. Container lock system providing carriage security in the event of carriage
-. Secure side barriers
-. Telescopic boom movement security system
-. Load holding valve on pistons in the event of hose tear
-. Booms made of high resistant iron sheet
-. Suitable transport all kind of garbage

Vehicle assembly line is the longest general assembly line of heavy commercial vehicles in Asia. The whole production line is composed of pre line assembly line, trim line, engine assembly line and axle assembly line etc. SINOTRUK has the most advanced fully automatic nut tightening machine, pipe packing machine, transmission shaft packaging and assembly facilities and various liquid filling machines, electrical testing instrument and so on. Guarantee the quality of the vehicle assembly strongly.

Howo Truck Gearbox

Model Number

QDZ5251ZYSA

Chassis Number

ZZ1257N4341W

Driving type

6*4

Rated Loading Weight(kg)

10000

Kerb Weight(kg)

15000

Total Mass(kg)

25000

Overall dimesion(L*W*H)mm

9980*2500*3650

Min. Turning Circle (m)

21.6

Max. Speed (Km/h)

Fuel Consumption(L/100km)

Engine

SINOTRUK Brand,WD615.47,EURO-2

Horse Power(hp/r/min)

371/2200

Volume of the Body(m3)

18.5

Volume of the Filler(m3)

2.5

Time of one Loading Cycle(s)

<25

Time of one Unloading Cycle(s)

<40

Max Brake Crase Pressure(kgf)

>35000

Transmission

HW19710, 10 forward and 2 reverse

Clutch

Dia.430mm, Hydraulically operating with air assitance

Front Axle

HF7

Rear Axle

ST16

Steering

ZF8098

Brake

Dual circuit compressed air service bake, spring energy parking brake, engine exhaust auxiliary brake, ABS for option

Tyre

12.00R20 Radial tyre

Product Images

Howo Gearbox Truck | sinotruk howo price in china | chinese garbage truck | sino trucks for sale in china

High Reliability

Introduce the original German MAN TG series vehicle technology, the same product design and the same production assembly technology, completely adopt the German standard in the production conformity management, testing & validation and the product release, and synchronize the parts purchasing system with MAN company, allof which are the strong guarantee of the vehicle high reliability.

Engine

DERIVING FROM MAN AND IMPROVED IN CHINA MC11 engine has a very wide area of low oil consumption and large torque, The minimum specific fuel consumption is only 186 g/kw / h; The internal mileage of the engine oil change can reach 80000 kilometers.Its B10 life could reach 1.5 million kilometers.
