Howo Truck Gearbox

Automatic GradeAutomatic
Weight (KG)25000kg
ChassisHowo
Horsepower371/2200
Fuel Tanker400L
Howo Truck Gearbox

Description

Howo Truck Gearbox produced by sinotruk Howo serves the specialized purpose of efficiently gathering urban residents’ household waste and other compressible refuse. Comprising a sealed garbage compartment, a hydraulic system, and an operational interface, this vehicle operates as a cohesive unit.

Its design ensures complete containment throughout the processes of self-compression, self-dumping, and compression, channeling all wastewater into a dedicated sewage tank. Notably, the pivotal components of packer garbage trucks are sourced as imports, boasting superior performance metrics such as high-pressure capabilities, impeccable sealing mechanisms, ease of operation, safety provisions, and labor-saving functionalities. This amalgamation of features not only guarantees operational efficiency but also underscores the packer garbage truck’s capacity to navigate the demands of urban waste management with precision and reliability.

Howo Truck Gearbox
Model Number QDZ5251ZYSA
Chassis Number ZZ1257N4341W
Driving type 6*4
Rated Loading Weight(kg) 10000
Kerb Weight(kg) 15000
Total Mass(kg) 25000
Overall dimesion(L*W*H)mm 9980*2500*3650
Min. Turning Circle (m) 21.6
Max. Speed (Km/h) 90
Fuel Consumption(L/100km) 29
Engine SINOTRUK Brand,WD615.47,EURO-2
Horse Power(hp/r/min) 371/2200
Volume of the Body(m3) 18.5
Volume of the Filler(m3) 2.5
Time of one Loading Cycle(s) <25
Time of one Unloading Cycle(s) <40
Max Brake Crase Pressure(kgf) >35000
Transmission HW19710,  10 forward and 2 reverse
Clutch Dia.430mm, Hydraulically operating with air assitance
Front Axle HF7
Rear Axle ST16
Steering ZF8098
Brake Dual circuit compressed air service bake, spring energy parking brake, engine exhaust auxiliary brake, ABS for option
Tyre 12.00R20 Radial tyre

Product Images

Howo Truck Gearbox | china special truck | chinese garbage truck | cnhtc truck price

Howo Truck Gearbox | china special truck | chinese garbage truck | cnhtc truck price

Howo Truck Gearbox | china special truck | chinese garbage truck | cnhtc truck price

High Reliability
High Reliability
Introduce the original German MAN TG series vehicle technology, the same product design and the same production assembly technology, completely adopt the German standard in the production conformity management, testing & validation and the product release, and synchronize the parts purchasing system with MAN company, allof which are the strong guarantee of the vehicle high reliability.
Engine
Engine
DERIVING FROM MAN AND IMPROVED IN CHINA MC11 engine has a very wide area of low oil consumption and large torque, The minimum specific fuel consumption is only 186 g/kw / h; The internal mileage of the engine oil change can reach 80000 kilometers.Its B10 life could reach 1.5 million kilometers.
