Dimensions:5800*3100*1800mm
Engine:WP12.430E201, EURO II
Mini Trucks China Specification
Its self-unloading function is a highlight, through the hydraulic system, the carriage can be automatically tilted to achieve rapid unloading, greatly improving the work efficiency. This feature makes the Mini Trucks China widely used in construction sites, building materials transportation, municipal engineering and other fields.
At the same time, the Mini Trucks China also performs well in terms of fuel economy, which can reduce operating costs and bring more economic benefits to users.
Although the size of the light truck is relatively small, its carrying capacity cannot be underestimated. It can meet the transportation needs of a certain weight of goods and ensure the safe delivery of goods.
All in all, Mini Trucks China is a powerful, practical and convenient means of transport, which has made important contributions to the development of modern logistics and transportation industry. Whether in urban construction or cargo transportation, it has shown unique value and advantages.
Mini Trucks China Parameters
Chassis Model
|
ZZ1047C2813C145
|
Drive Type
|
4×2
|
Engine
|
490,85HP Displacement : 2.5454L
|
Cabin
|
1760 single row(with one sleeper, air-conditioner and new-style seat)
|
Transmission
|
WLY525(5 forwards & 1 reverses)
|
Front Axle
|
2 Tons
|
Driving Axle
|
3.5 Tons
|
Clutch
|
hydraulically operating with air assistance
|
Rim/ Tire
|
6.50R16,Radial tire,
|
Wheel base
|
2800(mm)
|
Dimension of cargo body
|
3650*1810*400mm, Bottom:3mm Side:1.5mm
|
Overall dimension
|
5480×1950×2450mm
|
The curb weight
|
2370(Kg)
|
Gross weight
|
4495 kg
|
Max. speed
|
95km/h
|
Color
|
White, red, green, golden and so on.
|
