Sinotruk 6 Wheeler Dump Truck

Vehicle typeDump Truck
Max load (kg)30000
Power336-420hp
Dimension (mm)8614x2496x3450
CabinC7H-G, 2-berths
Sinotruk 6 Wheeler Dump Truck

Description

Our Sinotruk 6 Wheeler Dump Truck 336 hp truck also has 8×4, 420hp, and more different configurations, Euro 2/4 Emission Standard can provide.

As the first class agent of SINOTRUCK , we can export the SINOTRUCK brand tractor head, dump truck, fuel tanker truck, water tanker truck, cargo truck, concrete mixture truck, etc with great price and service advantages.

1. Oil saving, safety, driving comfort, reliability, low application cost
2. Engine, Sinotruk engine, 420HP, German man technology
3. T-type, middle or front lifting type
4. Tipper body: square or U-shaped
5. Tipper body: 15 to 20cbm
6. Heavy-duty load capacity: 30 to 40 tons
7. Floor thickness: 4 to 8mm,Side wall thickness: 3 to 6mm for customers different use
8. Hydraulic system: HYVA brand or Chinese famous brand

Sinotruk 6 Wheeler Dump Truck Description

Truck Models

ZZ3257M3647C

Truck Brand

SINOTRUK-HOWO

Driving Style

LHD

Dimension (LxWxH)(unloaded)(mm)

8614x2496x3450

Cargo body size (L*W*H, mm)(mm)

5800x2300x1500

Cargo thickness (mm)

Bottom: 8mm, Side: 6mm

Lift type of Carriage

middle lifting

Approaching angle/Departure angle (°)

19/26

Overhang (front/rear) (mm)

1500/1739

Wheel base (mm)

3825+1350

Max speed (km/h)

75

Maximum gradeability (%)

40

Minimum ground clearance (mm)

314

Minimum turning circle (m)

20

Curb weight (kg)

12290

Loading Weight (kg)

30000

Fuel tanker capacity (L)

300

Fuel consumption (L/km)

23L/100 km

Clutch

Single-plate dry clutch Φ430mm

Engine Model (Steyr technology, made in China)

Fuel type

Diesel

Horse Power, max(kw/rpm)

336hp

Emission

EURO II

Model

WD615, water-cooled, four strokes, 6 cylinders in line with water cooling, directly injection

Bore

126mm

Stroke

130mm

Compression ratio

29.8hp/l

Specific fuel consumption

195g/kwh

Transmission

Model

HW19710, 10 forwards and 2 reverse

Brake system

Service brake

Dual circuit compressed air brake

Parking brake

spring energy, compressed air operating on rear wheels

Auxiliary brake

Engine exhaust brake

Steering system

Model

ZF8118 hydraulic steering with power assistance

Front axle

HF9

Rear axle

HC16

Tyre

12.0020

Electrical system

Battery

2X12V/165Ah

Alternator

28V-1500kw

Starter

7.5Kw/24V

Cab

HW76cabin, one sleeper, with air conditioner





Product Images

High Reliability
High Reliability
Introduce the original German MAN TG series vehicle technology, the same product design and the same production assembly technology, completely adopt the German standard in the production conformity management, testing & validation and the product release, and synchronize the parts purchasing system with MAN company, allof which are the strong guarantee of the vehicle high reliability.
Engine
Engine
DERIVING FROM MAN AND IMPROVED IN CHINA MC11 engine has a very wide area of low oil consumption and large torque, The minimum specific fuel consumption is only 186 g/kw / h; The internal mileage of the engine oil change can reach 80000 kilometers.Its B10 life could reach 1.5 million kilometers.
