Engine Power:540
Full mass:32000 kg
Sitrak c7h 540 Hp Specification
The Sitrak C7H 540 hp is a heavy-duty commercial vehicle that is designed to provide exceptional performance, reliability, and efficiency. It is equipped with a powerful and highly efficient Sitrak engine that generates high levels of power and torque, making it ideal for hauling heavy loads over long distances.
The Sitrak C7H 540 hp features a spacious and comfortable cabin that is designed to provide a comfortable and ergonomic workspace for drivers, enhancing their safety and well-being on the road. Additionally, the Sitrak C7H 540 hp is equipped with advanced safety features, including electronic stability control, airbags, and anti-lock braking systems, which help reduce the risk of accidents and improve overall safety.
Sitrak c7h 540 Hp Parameter
Drive mode |
4×2 |
|||
Overall dimension |
L×W×H (mm) |
6220×2496×3410,3620,3960,3980 |
||
Wheelbase (mm) |
3600 |
|||
Front / rear wheel base (mm) |
2022,2041/1816 |
|||
Max. total mass (kg) |
18000 |
|||
Curb weight (kg) |
6800 |
|||
Cab |
Space size |
C7H-P (wide body and medium / high roof), C7H-G (wide body and high roof), C7H-F (medium-wide body and middle / high roof), C7H-U (medium-wide body and high roof) |
||
External |
4-point full-floating cab suspension, double toolkits, one-touch lifting window, MAN proprietary technology door hinge |
|||
Internal |
Air seat with waist cushion, pneumatic adjustable steering wheel, VDO instrument, height-adjustable safety belt, electrical adjustable rearview mirror, rearview mirror electrical heater, skeleton-type berth Dimension of lower berth (mm): Wide-body cab: 2,184×675, medium-wide body cab: 1,986×625 Dimension of upper berth (mm): Wide-body cab: 2,137×701, medium-wide body cab: 1,936×701 |
|||
Engine |
Emission standard |
China III |
||
Engine model |
MC11.35-30 |
MC11.39-30 |
MC11.43-30 |
|
Max. net power / speed |
257/1900 |
287/1900 |
316/1900 |
|
Max. torque / speed |
1800/1000-1400 |
1900/1000-1400 |
2100/1000-1400 |
|
Transmission |
Model |
ZF16S1870 |
ZF16S1950 |
ZF16S221 OD |
First gear / top gear ratio |
15.39/0.85 |
11.64/0.83 |
13.80/0.84 |
|
Clutch |
430A |
430A |
Built-in clutch assembly |
|
Drive axle |
Model |
MCY13 |
MCY13Q |
|
Ratio |
3.08, 3.36, 3.7, 4.11 |
|||
Suspension system |
Front / rear less-leaf spring suspension |
Front / rear less-leaf spring suspension, HUV suspension (optional) |
||
Saddle |
Jost 50 international standard saddle |
Jost 90 international standard saddle |
||
Front axle |
HF7disc brake (standard configuration: SKF bearing) |
|||
Steering system |
ZF8098 steering gear and ZF steering oil pimp |
|||
Braking system |
ABS (WABCO braking system), VOSS fittings, TMD disc brake friction block, ASR+EBL+TPM (optional) |
|||
Air intake system |
MANN+HUMMEL air filter |
|||
Fuel tank |
400 L, optional 560 L (only for 4×2 and 6×4 China III) |
|||
Tyre |
PIRELLI 315/80R22.5, MICHELIN tyres (optional) |
|||
Others |
Automatic slack adjuster (standard configuration), tachographs, integrated fender, split side protection, and fleet management system (optional) |
